50mm Clamp Type Current Transformer For Power Quality Analyzer

Ask Lasest Price
Brand Name :	HNMC
Model Number :	Q50B
Payment Terms :	L/C, T/T, Western Union, MoneyGram
Delivery Time :	4-8weeks

Add to Cart

Product Details
Company Profile

50mm Clamp Type Current Transformer For Power Quality Analyzer

JawΦ50mm AC Current Probe clamp transformer MODEL Q50B

Custom AC Permalloy Current Probe 1000A / 5A for Ethernet Power Meter

The Q50A is a 1000 Amp current probes which can measure 0-1000A cable while measuring without power off. Permalloy current probe Q50A features a 2 in. (50 mm) jaw size and high linearity. Product comes with a year warranty. Color has blue and grey as options.

Applications

Electric energy meter calibrator (on site)

Double clamp type ground resistance tester

Double clamp type phase volt-ampere meter

Digital multi-meter

Multi-function energy meter

Power quality analyzer

Matched instruments
Calibration instrument on site

Features

Suitable for 1000A cable online measurement.Holding wire diameter: φ50mm

Dimension: 101mm×219mm×26mm

Load capacity: mA output≤4Ω, 1A output 0.1Ω, 5A output 2.5VA

Installation: clamp type

Output mode: lead output

Parameter

Primary current	Secondary current	Class %
10A	2.5mA	0.1,0.2,0.5
10A	5mA	0.1,0.2,0.5
20A	5mA	0.1,0.2,0.5
100A	20mA	0.1,0.2,0.5
100A	40mA	0.1,0.2,0.5
100A	50mA	0.1,0.2,0.5
100A	100mA	0.1,0.2,0.5
200A	80mA	0.1,0.2,0.5
200A	100mA	0.1,0.2,0.5
200A	200mA	0.1,0.2,0.5
300A	120mA	0.1,0.2,0.5
300A	150mA	0.1,0.2,0.5
300A	200mA	0.1,0.2,0.5
300A	300mA	0.1,0.2,0.5
500A	100mA	0.1,0.2,0.5
500A	200mA	0.1,0.2,0.5
500A	250mA	0.1,0.2,0.5
500A	500mA	0.1,0.2,0.5
600A	120mA	0.1,0.2,0.5
600A	200mA	0.1,0.2,0.5
600A	300mA	0.1,0.2,0.5
600A	400mA	0.1,0.2,0.5
600A	500mA	0.1,0.2,0.5
600A	600mA	0.1,0.2,0.5

Primary current	Secondary current	Class %
700A	200mA	0.1,0.2,0.5
700A	350mA	0.1,0.2,0.5
700A	700mA	0.1,0.2,0.5
700A	700mA	0.1,0.2,0.5
800A	160mA	0.1,0.2,0.5
800A	200mA	0.1,0.2,0.5
800A	250mA	0.1,0.2,0.5
800A	320mA	0.1,0.2,0.5
800A	400mA	0.1,0.2,0.5
800A	500mA	0.1,0.2,0.5
800A	800mA	0.1,0.2,0.5
500A～800A	1A	0.2,0.5
600A～800A	1A	0.1,0.2,0.5
200A	5A	1.0
300A～500A	5A	0.5
500A～800A	5A	0.2,0.5
Ground resistance tester	Special instrument	0.1,0.5
